A2F Type Cable Gland for all types of unarmoured cables.
We are India's leading manufacturer, supplier, and exporter of A2F Type Single Compression Cable Glands.
| Type | A2F Type Single Compression Cable Gland |
|---|---|
| Cable Types | Unarmoured |
| Application | For indoor and outdoor use with all types of unarmoured cable where it is essential to provide IP66 or IP68 protection on the outer sheath of cable for circular, Unarmoured plastic or rubber sheathed cables. |
| Option Thread | Metric, NPT, BSP & PG |
| Gland Material | Brass (CuZn39Pb3), Stainless Steel (304 or 316L), Aluminium (6082) |
| IP Rating | IP66 & IP68 |
| Seal type | Displacement type |
| Operating Temperature | Standard seals (Nitrile): -20°C to 80°C. on request (silicone) : -60°C to +180°C |
| Finish | Natural Brass or Nickel Plated or Electroless Nickel Plated |
| Accessories | PVC/LSF Shroud, Lock Nut, Earth Tag, Serrated Washer, Adaptor / Reducer |
| IECEx Certificate No. | IECEx PRE 20.0124X |
| ATEX Certificate No. | Presafe 20 ATEX 48906X |
| EAC Certificate No. | RU C-IN.AA71.B.00212/20 |
| Protection Type | Ex d, Ex e, Ex t |
AVAILABLE ENTRY THREAD “C” (ALTERNATE METRIC THREAD LENGTHS AVAILABLE)
Size Chart / Specification
| CODE | CABLE GLAND SIZE | ENTRY THREAD "C" | THREAD LENGTH "E" | CABLE DIAMETER "A" | M | N | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| METRIC | NPT | OPTIONAL NPT | METRIC | NPT | MIN | MAX | MAX | MAX | ||
| MM-EX-A2F-20S16 | 20S16 | M20 | 1/2" | 3/4" | 17 | 20 | 3.2 | 8.5 | 24 | 26.5 |
| MM-EX-A2F-20S | 20S | M20 | 1/2" | 3/4" | 17 | 20 | 6.2 | 11.6 | 24 | 26.5 |
| MM-EX-A2F-20 | 20 | M20 | 1/2" | 3/4" | 17 | 20 | 8.0 | 13.9 | 27 | 30 |
| MM-EX-A2F-25 | 25 | M25 | 3/4" | 1" | 17 | 21 | 11.2 | 19.6 | 36 | 40 |
| MM-EX-A2F-32 | 32 | M32 | 1" | 1.1/4" | 17 | 26 | 17.1 | 26.0 | 42 | 46 |
| MM-EX-A2F-40 | 40 | M40 | 11/4" | 1.1/2" | 17 | 26 | 23.6 | 31.6 | 50 | 55 |
| MM-EX-A2F-50S | 50S | M50 | 11/2" | 2" | 17 | 26 | 31.1 | 37.5 | 55 | 60 |
| MM-EX-A2F-50L | 50 | M50 | 2" | 2.1/2" | 17 | 27 | 35.7 | 43.1 | 61 | 65 |
| MM-EX-A2F-63S | 63S | M63 | 2" | 2.1/2" | 17 | 27 | 41.6 | 48.7 | 70 | 77 |
| MM-EX-A2F-63L | 63 | M63 | 21/2" | 3" | 17 | 40 | 47.3 | 55.2 | 74 | 81 |
| MM-EX-A2F-75S | 75S | M75 | 21/2" | 3" | 17 | 40 | 54.1 | 61.2 | 80 | 87 |
| MM-EX-A2F-75L | 75 | M75 | 3" | 3.1/2" | 17 | 42 | 61.2 | 67.2 | 91 | 93 |
| MM-EX-A2F-90 | 90 | M90 | 31/2" | 4" | 24 | 44 | 66.7 | 79.2 | 108 | 116 |
- * Degrees of protection (IP Code) : IP66 / IP68 (1.5 meter, 2 Hours)
- * All the dimensions given are in Millimeters (mm)
- * Can be also provided in Kit Packing as per requirement
Disclaimer: Product sizes mentioned in the catalogue are for reference purpose only. The actual dimensional details would be available only after request based on the actual requirement.
